SA1160-sUTA-G96 Electronic Turbo Actuator Repair For Hella TBD For Garrett 797863-0096

TYPICAL APPLICATIONS

SACER SA1160-sUTA-G96 Smart Electronic Actuators are typically used for Garrett VNT turbo (applications such as passenger car / LDV duty diesel engines to help provide optimum performance and enable compliance with current and future exhaust emissions standards.

G NO./6NW NO.

TBD

Garrett Turbo NO.

797863-0096

Connector position

middle

Features

Lever angle tolerance ≤ +/-1.5degree Lever clearance tolerance ≤+/- 1.75 degree Lever move torque ≥ 2.5 Nm High quality laser welding Power supply : DC 14V (Range: 10.5V to 16V) Temp. range(Operation): -40℃ to +125℃ Temp. range(Storage): -40℃ to +150℃

Quality control

Full function OQC test and confirm for every unit. 2 years Full European Warranty Finish full function test, temperature test, endurance test, drop test, vibration test, salt spray test, destructive test, EMC test.
