SA1161-099-02 Electronic Turbo Actuator Gearbox Repair OE 6NW010099-02 For BMW X5 (E53) 3.0d (184 Hp) BMW 1,3 Series 2.0D
SA1161-099-02 Turbo Actuator Gearbox With brass worm and side connector,without cap
SACER SA1161-099-02 Smart remote actuator Gearbox is designed for the small displacement engine application with electronic control turbocharger, such as e-WGT, e-VG turbo. Smart rotating position feedback module and PWM interface feature provide high benefi ts for turbocharger effective control.
TYPICAL APPLICATIONS
SACER SA1161-099-02 Smart Electronic Actuator Gearbox is typically used for Garrett VNT turbo (applications such as passenger car / LDV duty diesel engines to help provide optimum performance and enable compliance with current and future exhaust emissions standards.
Order NR.
SA1161-099-02
Type
PWM / Digital
Reference Number
6NW 010 099-02
Parts Number
49335-19400
Make/Model
BMW X5 (E53) 3.0d (184 Hp) BMW 1,3 Series 2.0D
Features
Motor torque output:Up to 60Ncm (25℃) Resolution:0.26℃ Response time:<1.2ms Rotation travel:up to 120℃ Operating temperature range:-40℃ to 125℃ Communication:PWM Power input:10.5-16V
Quality control
Full function OQC test and confirm for every unit. 2 years Full European Warranty Finish full function test, temperature test, endurance test, drop test, vibration test, salt spray test, destructive test, EMC test.
